Shop Pumps & Filters

CMBE 5-62

$5,940.90 (Incl GST)

incl GST

Suitable for

  • Commercial water pressure boosting
  • Domestic water pressure boosting

Compact booster set for water supply in light commercial applications. Pump materials in contact with the liquid are in stainless steel (EN 1.4301)

cmbe pages

Description

Specifications

Product name CMBE 5-62 I-U-C-A-D-B
Product No 98374712
EAN number 5711493909521
Price

Technical

Pump speed on which pump data are based 3868 rpm
Rated flow 6 m³/h
Rated head 47.8 m
Impellers 4
Primary shaft seal AVBE
Approvals and markings CE
Curve tolerance ISO9906:2012 3B
Model A
Return valve YES
Start pressure Integrated Frequency converter

Materials

Pump housing Stainless steel
DIN W.-Nr. 1.4301
AISI 304
Impeller Stainless steel
DIN W.-Nr. 1.4301
AISI 304
Rubber EPDM

Installation

Maximum ambient temperature 55 °C
Flange standard WHITWORTH THREAD RP
Pump inlet Rp 1 1/4
Pump outlet Rp 1

Liquid

Pumped liquid Water
Liquid temperature range 0 .. 60 °C
Selected liquid temperature 20 °C
Density 998.2 kg/m³

Electrical data

Rated power – P2 1.5 kW
Mains frequency 50 / 60 Hz
Rated voltage 1 x 200-240 V
Maximum current consumption 9.10-7.60 A
p max system 10 bar
Rated speed 360-4000 rpm
Enclosure class (IEC 34-5) IP55
Insulation class (IEC 85) F
Type of cable plug AU
Mains cable 1.5 m

Tank

Tank volume 2 l

Others

Net weight 19.3 kg
Gross weight 29.3 kg
Sales region Australia
Config. file no 98499013



Additional information

Weight 25 kg
